Traditional Medicine Cabinet

Applications

The Table is designed and manufactured for the purpose of dividing and packing Traditional Medicines, Herbal Medicines in Hospitals, Clinics, Health Facilities of Precinct & Commune…

Main features

- Cabinet body is made of Sapele wood that are processed to protect against termite, warping and polished on the surface, light brown/natural wood’s color, thickness 18mm ±3%

- The upper part of the cabinet is divided by a partition forming 2 chambers. Each chamber consists of 4 compartments formed by 3 wooden panels. Each wooden panel withstand loads up to 10kg if load spread evenly on the surface. The entire upper part of the cabinet has 8 compartments.

- The front of the upper part of cabinet is blank.

- The lower part of the cabinet is divided by 3 partitions forming 4 chambers. Each chamber consists of 3 compartments formed by 2 wooden panels. The entire lower part of the cabinet has 12 compartments.

- Each compartment has a drawer with metal handle, withstand loads up to 15kg, the front has a tag holder to name medicine.

- There are 4 leveller foots under the cabinet plinth panel to prevent limp and wet

Technical data

Style/Model:	TMC-19.01
Height of Cabinet not including leveller Foot	1990mm ± 3%
Width of Cabinet	2000mm ± 3%
Dimension of the Upper Part	Hight x Width x Depth: 1090 x 2000 x 300 (mm) ±3%
Dimension of the Lower Part	Hight x Width x Depth: 900 x 2000 x 600 (mm) ±3%
Height of Cabinet Plinth Panel	50mm ±3%
Inner Dimension of a Compartment in the Upper Part of the Cabinet	4 Upper Compartments, each (Height x Width): 200 x 973 (mm) ±3% 4 Lower Compartments, each (Height x Width): 300 x 973 (mm) ±3%
Inner Dimension of a Compartment in the Lower Part of the Cabinet	Height x Width: 259 x 477 (mm) ±3%
