Applications

Major surgery, major surgery, minor surgery; General surgery, laparoscopic surgery, chest surgery, orthopedic surgery, plastic surgery, maternity surgery, urology surgery, brain surgery, etc.

Main features

- The device uses high frequency current to cut and stop bleeding. The device also applies digital technology for high quality and safety. The device uses power from 90 VAC to 250 VAC.
- Remote control with 3-function pedal. Large capacity, working with high frequency.
- The working modes are optimally designed and installed scientifically to help doctors easily operate.
- The equipment is tropicalized, suitable for the climate of Vietnam.

Technical data

Working frequency
450 kHz
Working mode
CUT 1
Pure cut
10 - 350W
CUT 2
Cut - stop superficial bleeding
10 - 250W
CUT 3
Cut - stop bleeding deeply
10 - 150W
COAG
Unipolar hemostasis
10 - 150W
BIPOLAR
Bipolar hemostasis
1 - 120W
Alarm function
In case of a lack of neutral, the computer will signal and emit "Tu Tu", the screen appears "-P-" and the ERR light turns on.
Works in water - laparoscopic surgery
Forced cooling system
The effect automatically measures the tissue resistance, stabilizes the cutting power
From 100Ω to 2500Ω (default)
Leakage of high frequency current
≤ 100mA
Working conditions
Operates continuously 24/24 hours
Cut cycle allowed
Cut every 3 minutes
Pause for 30 seconds / time
Foot pedal control
CUT - COAG - BIPOLAR
Power Consumption
0.5 kW - 1 kW (pulse)
Temperature
≤ 40°C
Humidity
≤ 90%
Effect
Effect 1,2,3,4 increases cutting performance
Supply voltage
90 - 250V; 50/ 60Hz
Size
87 x 45 x 39 cm
Weight
23 kg

Catalogue/Brochure

** Please do not hesitate to contact us for more informations
